Model TP-SGW is electric chain block designed for heavy duty industrial applications and significantly reduce downtime and operation cost. The hoist can easily handle large loads and require little maintenance.
Features:
SHELL:
Light aluminum alloy shall be adopted, which is light but hard and fit for the use in the terrible work environment with a high heat dissipation rate and all tightness design.
INVERSE PHASE SEQUENCE PROTECTING DEVICE:
It is the special electrical installation which controls the circuit not to work in case of wiring error in the power supply.
LIMIT SWITCH:
The limit switch device is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety.
24V/36V DEVICE:
It is used to prohibit the emergencies from occurring in case of the leakage in the switch.
SIDE MAGNETIC BRAKING DEVICE:
This device shall realize the instant brake in case of the power dump.
CHAIN BAG:
It shall be light, handsome and durable.
CHAIN:
The chain shall adopt the imported FEC G80 ultra heat-treatable aluminum alloy chain.
Our advantages
1. Provide OEM service.
2. The same quality product with the best price.
3. We are specialized in the field of lifting equipment and rigging product supply for around 10 years, with rich experience in Production.
Specification
SGW electric hoist single speed size specification
Model | H(mm) | A(mm) | B(mm) | D(mm) | E(mm) | I(φ)(mm) | J(mm) | K(φ)(mm) | L(mm) | M(mm) | N(mm) |
SGW-00501 | 550 | 460 | 230 | 280 | 160 | 35 | 25 | 35 | 25 | 17 | 17 |
SGW-01001 | 650 | 520 | 260 | 300 | 176 | 40 | 31 | 40 | 31 | 22 | 22 |
SGW-01002 | 670 | 460 | 230 | 280 | 205 | 40 | 31 | 40 | 31 | 22 | 22 |
SGW-01501 | 800 | 615 | 295 | 430 | 265 | 47 | 40 | 47 | 38 | 30 | 30 |
SGW-02001 | 800 | 615 | 295 | 430 | 265 | 47 | 40 | 47 | 38 | 30 | 30 |
SGW-02002 | 835 | 520 | 260 | 300 | 236 | 47 | 38 | 47 | 38 | 30 | 30 |
SGW-02501 | 845 | 615 | 295 | 430 | 265 | 58 | 47 | 58 | 47 | 36 | 36 |
SGW-03001 | 845 | 615 | 295 | 430 | 265 | 58 | 47 | 58 | 47 | 36 | 36 |
SGW-03002 | 950 | 615 | 295 | 430 | 320 | 58 | 47 | 58 | 47 | 36 | 36 |
SGW-05002 | 1030 | 615 | 295 | 430 | 325 | 60 | 48 | 60 | 48 | 43 | 43 |
SGW-10004 | 1400 | 630 | 315 | / | 890 | 85 | 80 | 80 | 80 | 104 | 55 |
SGW electric hoist single speed technical parameters
Model | Rated load(Ton) | Standard Lifting Height(m) | Lifting speed(m/min) | Hoist Motor 3-phase(voltage 200-440V) | Chain Falls | Chain Specification(φ) | Test Load(t) | Weight(kg) | Weight Added with 1m Higher(kg) | ||
Power(kw) | Ratation Speed(r/min) | Frequency(Hz) | |||||||||
SGW-00501 | 0.5 | 3 | 6.8 | 0.75 | 1440 | 50 | 1 | 6.3 | 0.625 | 47 | 0.81 |
SGW-01001 | 1 | 3 | 6.6 | 1.5 | 1440 | 50 | 1 | 7.1 | 1.25 | 61 | 1.1 |
SGW-01002 | 1 | 3 | 3.4 | 0.75 | 1440 | 50 | 2 | 6.3 | 1.25 | 52 | 1.62 |
SGW-01501 | 1.5 | 3 | 8.8 | 3 | 1440 | 50 | 1 | 10 | 1.875 | 108 | 2.3 |
SGW-02001 | 2 | 3 | 6.6 | 3 | 1440 | 50 | 1 | 10 | 2.5 | 115 | 2.3 |
SGW-02002 | 2 | 3 | 3.3 | 1.5 | 1440 | 50 | 2 | 7.1 | 2.5 | 73 | 2.2 |
SGW-02501 | 2.5 | 3 | 5.4 | 3 | 1440 | 50 | 1 | 11.2 | 3.125 | 116 | 2.8 |
SGW-03001 | 3 | 3 | 5.4 | 3 | 1440 | 50 | 1 | 11.2 | 3.75 | 122 | 2.8 |
SGW-03002 | 3 | 3 | 4.4 | 3 | 1440 | 50 | 2 | 10 | 3.75 | 131 | 4.7 |
SGW-05002 | 5 | 3 | 2.7 | 3 | 1440 | 50 | 2 | 11.2 | 6.25 | 151 | 5.6 |
SGW-10004 | 10 | 3 | 2.7 | 3 | 1440 | 50 | 4 | 11.2 | 12.5 | 300 | 8.4 |
Product Details
FAQ
Q1: Can provide customized products? OEM products or ODM products?
A1: Yes,we can provide customized products according to your requirement. Both OEM and ODM are acceptable.
Q2: Can we print the LOGO on products?
A2: Yes, the OEM is available with the permission of our customers.
Q3: How do you control your quality?
A3: 1. We only select high-quality steel material from famous steel group.
2. Standardized production process with traceable ID Card, every part can be tracked to the original records.
3. 100% finished product testing before shipping.
4. We accept third party product inspections.
5. ISO9001 Quality management system certificated factory
6. Supervised container loading process, ensures the last step security.
Q4: What are your advantages compared to the others?
A4: 1.Unique products, with customized service.
2.Timely production and delivery, time is money.
3.Market protection service, long term business strategy.
